CSP Multistage Submersible Pumps with Integrated Automatic Control

Max. fluid temperature: 40℃
Max. passage of suspended solid body: Φ 2mm
Continuous duty
Two-Pole induction motor (n=2900 r/min)
Insulation Class F
Protection IPX8
With capacitor and thermal overload protection

coming soon


Operating Limits:

Max. fluid temperature: 40℃

Max. passage of suspended solid body: Φ 2mm

Continuous duty


Motor:

Two-Pole induction motor (n=2900 r/min)

Insulation Class F

Protection IPX8

With capacitor and thermal overload protection


Material:

Inlet and outlet body: Plastic

Impeller: Plastic

Motor shaft: Stainless Steel

Double mechanical seals separated by an oil chamber

Mechanical seal: Ceramic / Graphite


Product Advantages:

Integrated pump control

Integrated dry run protection

Compact design

Medium-cooled motor

Corrosion-resistant


Product Description:

This pump is a multistage, medium-cooled submersible pump

for garden and domestic water supply. It can be used to reliably

supply rain water from a rainwater storage tank for toilets,

washing machines and garden watering. The intelligent pump

controller recognizes if the pump is running dry. In this event

the pump will try to start again, if there is still no water available

the pump turns off. This guarantees safe operation and high

efficiency. The electronics also protects the pump against defects

in the non-return valve that generally occur due to dirt or sand

encrustations.

The advanced submersible pump concept incorporates many

years of proven pump technology with a sophisticated control to

produce a compact and highly reliable product.
