Operating Limits:

Max.fluid temperature: 40℃

Max.passage of suspended solid body:Φ 2mm

Continuous duty

Motor:

Two-Pole induction motor (n=2900 r/min)

Insulation Class F

Protection IPX8

With capacitor and thermal overload protection

Copper wire motor

Material:

Inlet and outlet body: Plastic

Impeller: Plastic

Motor shaft: Stainless Steel

Double Mechanical seals separated by an oil chamber

Mechanical seal: Ceramic / Graphite

Application:

These pumps are used when the level of water to be drawn

off is located at a distance higher than 9 meters. Submerged,

they offer the advantage of being invisible, silent and less

subject to the risk of freezing. These pumps are supplied

with a safety system using a buoyancy device which ensures

the pump to stop automatically, if the well dries up.
