Operating Limits:

Max.suction head:8m

Max.liquid temperature:35℃

Max.ambient tempereature:40℃

Motor:

Two-pole induction motor(n=2900r/min)

Insulation class B

Protection IP68

Continuous service S1

Thermal protector

Single-phase 220V/50Hz, 60Hz if request

Material:

Pump body:Stainless steel/Technopolymer

Suction filter:Stainless steel

Impeller:Noryl

Motor shaft:Stainless steel

Mechanical seal: Ceramic/Graphite

Bearings:6201 RZ/6202 RZ

Application:

Suitable for use with clean water that does not contain

abrasive particles As a result of  their reliability and

the fact that they are easy to use, and suitable for use

in application such as domestic,gardening,irrigation and

emptying tanks.
