Motor:

The motor is a 4-pole synchronous permanent-magnet motor.

The pump controller is incorporated in the control box,

which is fitted to the stator housing and connected to

the stator via a terminal plug.

Materials:

Ceramic shaft and radial bearings.

Carbon thrust bearing .

Stainless-steel rotor shroud.

Composite material impeller.

Cast iron pump casing.

Features:

Automatic control of the differential pressure.

Suitable for installation in existing systems.

Automatic night setback, selectable.

Low-noise operation.

Alarms indicated in the display.

Wamnings indicated in the display

Applications:

One-pipe heating system.

Underfloor heating system.

Two-pipe heating system.

Domestic hot-water recirculation system.
