Motor:

Fully enclosed, air-cooled, two-pole standard motor

Protection level:IP55

Insulation grade:F

Standard voltage:

50HZ

1×220-230/240V

3×200-220/346-380V

Operating Conditions:

Maximum work pressure:

Conventional:1.0MPa

High pressure type:1.6MPa

Applicable temperature of liquid:-20°C~120°C

Ambient maximum temperature:40°C

Materials:

Pump body, pump cover, impeller material standards are gray cast.

Users can choose special materials according to their working conditions.

Applications:

Water supply system

Fire extinguishing system

Refrigerating system

Eletroplating industry

Chemical industry

Sewage treatment
