Operating Conditions:

5m maximum immersion depth

Liquid temperature up to 35°C

Maximum ambient temperature 40°C

Motor:

Two-pole induction motor(n=2900rpm)

Insulation class B

Protection level IP68

Continuous service S1

Thermal protector for single phase

Single-phase 220V/50Hz, 60Hz if request

Three-phase 380V/50Hz, 60Hz if request

Materials:

Pump body: Cast iron

Motor housing: Cast iron

Impeller: Cast iron

Motor shaft: Stainless steel

Applications:

Suitable for use with dirty water that is not chemically

aggressive towards the materials from which the pump

is made.

As a result of their reliability and the fact that they are

easy to use, and suitable for use in applications such as

clearing dirty water, discharging domestic waste water,

and for emptying collection traps containing partical up

to a maximum of Φ 40mm
