Operating Conditions:

Medium temperature: 5~50°C

Ambient temperature: ≤50°C

Max.working pressure: 0.3MPa

Motor:

Factory setting of electric pump speed in automatic mode:

speed 1: 3000rpm,

speed 2: 1400rpm,

speed 3: 2200rpm,

and the speed can be arbitrarily set between

450~3450rpm through the speed gear key

Materials:

Pump Body: PP+GF30

Impeller: PA66+GF30

Features:

Adopt V/F mode controller to realize the speed control function; Optional touch key panel or physical

key panel, simple design, simple operation, installation direction can be rotated.

Automatic mode and manual mode are optional. The factory default is automatic mode.

In the manual mode, the user can select the segment speed number to run and modify its speed.

The machine can be started and stopped by external keyboard or RS485 communication(only one

can be selected).

Efficient and energy-saving.

Applications:

Milk bubble system

Pool cleaner

Booster system

Agricultural irrigation

Industrial water supply
