Operating Conditions:

Medium temperature:0-75℃

Ambient temperature:≤50℃

Max.working pressure:0.7MPa

Motor:

Three-phase(Single-phase) induction machine

Insulation class: F

Protection class:IP55

Totally Enclosed Fan Cooled(TEFC)

Motor material:50W800

AC anti-creep bearing

Continuous service: S1

Materials:

Pump body: PP+GF

Impeller: PPO+GF

Motor shaft: 45# +SUS304

Mechanical seal: Graphite/silicon carbide/fluorine glue/SUS316

Motor housing:ADC12

Features:

Inlet and outlet flange are national standard DN100.It

also can be adapted to American ANSI.B16.5

flange standard.

Integrated plastic mounting base plate is provided as

standard.

High efficient motor, Energy saving, long durability.

Application:

Long safety operation under 75℃ medium, applicable

to natural Hot Spring water circulation.

Compatible large water world, aquarium and large

swimming pool.
