Operating Conditions:

Liquid temperature:5-70℃

Ambient temperature:0-40℃

Max.working pressure:1.0MPa

Motor:

Permanent magnet brushless motor

Insulation class: F

Protection class: IP54

Water-cooling

Motor material:DW470

Screen wall structure

Continuous service: S1

Materials:

Pump body:SS304

Impeller: SS304

Motor shaft: Ceramic

Motor housing:SS304

Features:

Stable performance: wide voltage 170-260V,wide

frequency 50-60Hz.

Smaller size, lighter weight,higher efficiency, lower noise

and stronger function.

Simple operation: pump can run and stop automatically

according to the user's requirements, the operation is

simple and convenient with only 2 buttons.

Smart fault diagnosis: pump will alarm, self-check and

fault prediction under abnormal conditions.

Water-cooled method drives motor and controller, no

fan cooling, which can reduce noise and improve motor

efficiency.

Ceramic shaft and ceramic bearing ensure water-using

safety.

The maximum outlet pressure can be inlet pressure

plus 3 bar.

Application:

Pressurized household water supply, such as tap water,

water tower, purification system, etc. circulation and

pressurization.
