Operating Limits:

Max. suction head: 8m

Max. liquid temperature: 50℃

Max. ambient temperature: 40℃

Continuous duty

Motor:

Two-Pole induction motor (n=2900 r/min)

Insulation Class F

Protection IP55

Material:

Pump body: AISI 304 Stainless Steel

Impeller/diffuser: Plastic

Motor Shaft: Stainless Steel

Mechanical seal: Ceramic/Graphite

Application:

Aggressive liquids transfer

Pumping and distribution of water in domestic systems used

on a continuous or intermittent basis.

Booster systems

Washing systems, garden irrigation, fountains
