Operating Limits:

Max. suction head: 8m

Max. liquid temperature: 60℃

Max. ambient temperature: 40℃

Continuous duty

Motor:

Two-Pole induction motor (n=2900 r/min)

Insulation Class B

Protection IPX4

Material:

Suction and discharge Mountings:Cast Iron

Pump casing:Stainless Steel

Impeller:Plastic/Stainless Steel

Motor Shaft:Stainless Steel

Mechanical seal:Ceramic/Graphite

Installation and Use:

These pumps are suitable to pumping clean water which is not

chemically aggressive to the pump components.

They are extremely reliable, simple to use, quiet and virtually

maintenance-free, finding many uses in flow irrigation systems

in gardening agriculture and industrial fittings.
