Operating Limits:

Max. liquid temperature: 60℃

H version: max.liquid temperature110℃

Max. ambient temperature: 40℃

Maximum working pressure: 8 bar

Motor:

Two-Pole induction motor(n=2900r.p.m.)

Insulation Class F

Protection Class IP55

Standard voltage: 1 phase 230V ± 10% 50Hz

3 phase 230/400V ±10% 50Hz

Single-phase: permanent split capacitor and

automatic thermal overload protection

Three-phase: thermal protection

Material:

Pump body, impeller, diffuser and casing cover in AISI 304

Shaft in AISI 304

Bracket and motor casing in aluminum

Mechanical seal in carbon/ceramic/NBR

Special mechanical seal are available on demand

Application:

Twin impeller centrifugal pumps with hydraulic components constructed in stainless steel AISI 304,

suitable for pressure boosting, water supply, water treatment & irrigation. Air conditioning systems

and general water pumping including moderately aggressive liquids.
