Operating Limits:

Max. liquid temperature: 50℃

Max. ambient temperature: 40℃

Max. operating pressure: 1.5MPa

Motor:

Two-Pole induction motor(n=2900r.p.m.)

Insulation Class F

Protection Class IP54

Standard voltage: 1x220-240V

3x220-240V/380-415V

Single phase motor mounted thermal protector

( three-phase motor can be based on customer

requirements to install thermal protector ).

Material:

Suction part and discharge part: Cast iron

Impeller: Stainless steel

Diffuser: Plastic

Motor Shaft: Stainless steel

Application:

Non-flammable or non-explosive clear water without abrasive or

fibre and not aggressive to stainless steel.

Water treatment (water purification ), industrial cleaning machine.

Floors of pressurized water supply.

High building boosting, water supply, garden sprinkler.

Air-conditioning and cooling system.

Firefighting system.

Aquaculture and other uses.
