Operating Limits:

Liquid temperature:

Normal temperature type +15℃~+70℃

Hot water type + 70℃ ~105℃

Max. ambient temperature: 40℃

Max. operation pressure: 10 bar

Max. inlet pressure is limited by Max. operation pressure

Continuous duty

Motor:

T.E.F.C. continuous duty

Voltage: 50Hz: 1x220~240V

 3x220~240V/380~415V

       60Hz: 1x220~240V

 3x220~240V/380~415V

Insulation class: F

Protection class: IP55

Speed: 2900rpm

Single-phase motor built in thermal protector

Materials:

Pump body, back-cover, impeller, shaft and

guide plate in AISI 304

Bracket and motor casing: Aluminum

Mechanical seal: Ceramic / Graphite / NBR

Applications:

The pumps are suitable for transporting clean

media which are non-aggressive to stainless

steel AISI304 or AISI316

Water supply systems

Pressure boiler feeding

Pure water treating systems

Pharmaceutical & food stuff

Refining chemical industries

Washing and sprinkling
