Operating Limits:

Max. suction head: 8m

Max. liquid temperature: 60℃

Max. ambient temperature: 40℃

Continuous duty

Motor:

Two-Pole induction motor (n=2900 r/min)

Insulation Class B

Protection IPX4

Material:

Pump body:Cast Iron

Impeller:Brass (or plastic)

Motor Shaft:Carbon Steel / AISI 420 Stainless Steel /

AISI 304 Stainless Steel

Mechanical seal:Ceramic / Graphite

Installation and Use:

They are recommended for pumping clean water and liquids

that are chemically non aggressive to the materials from

which the pump is made.

Reliable and maintenance free they are widely used in the

domestic and civil sector, in particular for water distribution in

combination with small or medium pressure sets, for transfer

in general, for irrigating gardens.

The pumps must be installed in closed places, or at least

protected against inclement weather.
