Operating Limits:

Max. suction head: 8m

Max. liquid temperature: 60℃

Max. ambient temperature: 40℃

Continuous duty

Motor:

Two-Pole induction motor (n=2900 r/min)

Insulation Class B

Protection IPX4

Material:

Pump Body:Stainless steel

Impeller:Stainless Steel/Brass/Plastic

Motor Bracket:Cast Iron (or Cast Aluminum)

Motor Shaft:AISI 420 Stainless Steel / AISI 304 Stainless Steel

Mechanical Seal:Ceramic / Graphite

Installation and Use:

They are recommended for pumping clean water and liquids

that are chemically non aggressive to the materials from which

the pump is made.

Due to their reliability and quiet running, they are suitable for

domestic applications including water suppler (as a pressure

set), garden irrigation, etc.

The pumps must be installed in closed places, or at least

protected against inclement weather.
