Operating Limits:

Max. suction head: 8m

Max. liquid temperature: 60℃

Max. ambient temperature: 40℃

Continuous duty

Motor:

Motor: Permanent Magnet Brushless DC

Motor(Without Hall)

Controller: 32bit MCU/FOC/Sine Wave Current/MPPT

Controller Shell: Die-cast Aluminum

Material:

Inlet/Outlet: 304 Stainless Steel

Pump Body: 304 Stainless Steel

Impeller: 304 Stainless Steel

Controller Shell: Die-cast Aluminum

Application:

They are recommended for pumping clean water

and liquids that are chemically non aggressive to the

materials from which the pump is made.

Due to their reliability and quiet running, they are suitable

for domestic applications including water suppler (as a

pressure set), garden irrigation, etc.

The pumps must be installed in closed places, or at least

protected against inclement weather.
