Operating Limits:

Max. suction head: 8m

Max. liquid temperature: 50℃

Max. ambient temperature: 40℃

Continuous duty

Motor:

Two-Pole induction motor (n=2900 r/min)

Insulation Class F

Protection IP55

Material:

Pump Body:AISI 304 Stainless steel

Impeller:Stainless Steel / Plastic

Motor Shaft:Stainless Steel

Mechanical Seal:Ceramic / Graphite / NBR

Installation and Use:

Pumping and distribution of water in domestic systems

used on a continuous or intermittent basis.

Booster systems

Washing systems, garden irrigation, fountains

Pumping from wells or tanks
