Operating Limits:
Max. suction head: 8m
Max. liquid temperature: 60℃
Max. ambient temperature: 40℃
Continuous duty
Motor:
Two-Pole induction motor (n=2900 r/min)
Insulation Class B
Protection IPX4
Material:
Pump Body:Cast Iron
Impeller:Brass/Plastic/Stainless Steel
Motor Shaft:Carbon Steel/AISI 420 Stainless Steel/AISI 304 Stainless Steel
Mechanical Seal:Ceramic / Graphite
Installation and Use:
They are recommended for pumping clean water and liquids
that are chemically non aggressive to the materials from
which the pump is made.
They are designed for suction lifts and can be positioned
above the water source, including applications with air
entrained in the water. Due to their reliability and low
maintenance, they are recommended for domestic use,
including water distribution (as part of a pressure set),
garden irrigation, etc.
The pumps must be installed in closed places, or at least
protected against inclement weather.
Operating Limits:
Max. suction head: 8m
Max. liquid temperature: 35℃
Max. ambient temperature: 40℃
Continuous duty
Motor:
Two-Pole induction motor(n=2900 r/min)
Insulation Class B
Protection IPX4
Material:
Pump Body:Cast Iron
Impeller:Brass/Plastic/Stainless Steel
Motor Shaft:Carbon Steel / AISI 420 Stainless Steel /AISI 304 Stainless Steel
Mechanical Seal:Ceramic / Graphite
Installation and Use:
They are recommended for pumping clean water and liquids that are chemically
non aggressive to the materials from which the pump is made. Jet self-priming
pumps are designed for suction lifts and can be positioned above the water source,
including applications with air entrained in the water. Due to their reliability and low
maintenance, they are recommended for domestic use, including water distribution
(as part of a pressure set), garden irrigation, etc.
