Operating Limits:

Max immersion depth: 5m

Max liquid temperature: +40℃

Liquid PH value: 5-9

Liquid kinematic ciscosity: 7×10-6~23×10-6 m2/s

Max liquid density: 1.2×103 kg/m3

Motor:

Copper winding

Built-in thermal protector

Stainless steel welded shaft

Insulation class: B

Protection class: IPX8

Material:

Pump body: HT200

Motor casing: AISI201

Impeller: HT200

Oil seal: NBR

Double mechanical seal: NBR

Application:

Wastewater drainage in factories, construction sites and commercial facilities

Drainage system in municipal sewage treatment plants

Drainage station in residential quarters

Municipal projects

Methane pools and field irrigation in countryside
