Operating Limits:

Max.depth: 5m

Max.fluld temerature: 40℃

Max.ambient temerature: 40℃

Continuous duty

PH: 6.5-8.5

Solid/Liquid: d<0.1%

Max.Dia.of particle: <2mm

Motor:

Two-Pole induction motor(n=2900r/min)

Insulation Class: B

Protection grade: IPX8

Material:

Pump body:Aluminum/Cast iron

Impeller:Aluminum/Plastic

Motor shaft:Stainless Steel/Carbon steel

Mechanical seal:Mechanical seal ceramic-graphite-NBR,

with oil barrier chamber and inner lip

seal to protect the seal in the event of dry running.

Application:

They are recommended for pumping clean water without

abrasive particles and liquids that are chemically

nonaggressive to the material of which the pump is made.

Mainly used for well pumping, river pumping, farm

irrigation, water supply, drainage in breeding Industry.
